Specific Extinction Spectra Of Sunscreen Filters

It is not uncommon to read that a specific filter is a blocker of a specific type of UV radiation. Indeed, most sources which provide information on cosmetics have a system of symbols which represents how well different filters block different types of radiation.

For example, on websites and databases which function to explain the function of cosmetic ingredients, one often sees systems like this:

Sunscreen UV Protection.jpg

I understand why filters are presented like this. It is good shorthand. I also take real umbrage with it. In that it is shorthand, it is reductive. The reality is about one trillion times more complex. My issues can be summarized:

  1. It presents UV radiation as a “Yes” or “No”for each category of wavelength. If a filter is said to filter UVB, one would be led to incorrectly assume that the filter offers a consistent level of UV extinction through the 30 individual wavelength of UVB. This is literally never the case with sunscreen ingredients. UV is a spectrum, and each wavelength of UV light delivers a unique amount of energy. The molecular composition of different sunscreen filters cause each filter to respond to different wavelengths of radiation differently.

  2. It provides no context for how efficient the UV filter is for each “category” of UV light. This is quite an issue. Some filters are much more absorptive than others. As in, to get any real protection from Meridamate, one needs to use a much higher quantity of it than one does Avobenzone.

The best way to understand the actual absorbing capability of a sunscreen filter is by looking at its specific extinction, which I’ve attempted to explain in the context of sunscreens here.

I will summarize briefly: specific extinction refers to the sunscreen ingredient’s absorbance in accordance with a fixed set of parameters: how much of each wavelength is made extinct through a 1cm long 1% concentration of the solubilized filter. Looking at specific extinction spectra provide a facile way to compare the effectiveness of isolated sunscreen filters. One can compare “apples to apples”: how well one filter did versus another, in accordance with the same set of parameters. Looking at a filter’s specific extinction allows one to determine which wavelengths it filters effectively, and the rate of that efficacy per filter.

It is worth stating that looking at the specific extinction of a filter will not give an absolute indication of how well the filter will perform in an actual sunscreen product. In real life, there are a myriad of other factors which will impact the protection of a sunscreen beyond the absorptive capability of the filters. Below is an incomplete list of things which can impact the actual absorbance of a sunscreen formula

  1. The vehicle cream
  2. Synergistic or photodegratory interactions between sunscreen filters
  3. The concentration at which the sunscreen filter is included in a product
  4. The filter’s photostability, and the rate of its potential degradation given the ambient UV in one’s environment
  5. Whether or not the filters are encapsulated, and if so, the encapsulation technology
  6. The concentration of emollients / antioxidants / other ingredients which impact the performance of the sunscreen filters

However, if one wants to look at the actual performance of a sunscreen formula – not a specific active ingredient – one must measure absorbance. Like specific extinction, Absorbance measures how much of the UV light failed to get from the start of a system to the end, but it allows for testing of sunscreen at the indicated dosage form, which Specific Extinction, obviously, does not.

That said, let’s look at the filters.

Broad Spectrum Filters

Tinosorb S (or Bemotrizinol); INCI: Bis-Ethylhexyloxyphenol Methoxyphenyl Triazine  EU: 10%; AU: 10%; JP: 3%; CA: 6%; US: N/A

Tinosorb S (or Bemotrizinol); INCI: Bis-Ethylhexyloxyphenol Methoxyphenyl Triazine

EU: 10%; AU: 10%; JP: 3%; CA: 6%; US: N/A

Tinosorb A2B (nano); INCI: Tris-Biphenyl Triazine (nano)  EU: 10%; AU: 10%; JP: 10%; CA: N/A; US: N/A

Tinosorb A2B (nano); INCI: Tris-Biphenyl Triazine (nano)

EU: 10%; AU: 10%; JP: 10%; CA: N/A; US: N/A

Tinosorb M (or Bisoctrizole); INCI: Methylene Bis-Benzotriazolyl Tetramethylbutylphenol  EU: 10%; AU: 10%; JP: 10%; CA: 5%; US: N/A

Tinosorb M (or Bisoctrizole); INCI: Methylene Bis-Benzotriazolyl Tetramethylbutylphenol

EU: 10%; AU: 10%; JP: 10%; CA: 5%; US: N/A

Mexoryl XL; INCI: Drometrizole Trisiloxane  EU: 15%; AU: 15%; JP: 15%; CA: 15%; US: N/A

Mexoryl XL; INCI: Drometrizole Trisiloxane

EU: 15%; AU: 15%; JP: 15%; CA: 15%; US: N/A

Zinc Oxide  EU: 25%; AU: No Limit; JP: No Limit; CA: 25% ; US: 25%

Zinc Oxide

EU: 25%; AU: No Limit; JP: No Limit; CA: 25% ; US: 25%

All of them!

All of them!

UVA Filters

Avobenzone; INCI: Butyl Methoxydibenzoylmethane  EU: 5%; AU: 5%; JP: 10%; CA: 3%; US: 3%

Avobenzone; INCI: Butyl Methoxydibenzoylmethane

EU: 5%; AU: 5%; JP: 10%; CA: 3%; US: 3%

Uvinul A Plus; INCI: Diethylamino Hydroxybenzoyl Hexyl Benzoate  EU: 10%; AU: 10%; JP: 10%; CA: N/A; US: N/A

Uvinul A Plus; INCI: Diethylamino Hydroxybenzoyl Hexyl Benzoate

EU: 10%; AU: 10%; JP: 10%; CA: N/A; US: N/A

Ecamsule; INCI: Terephthalylidene Dicamphor Sulfonic Acid  EU: 10%; AU: 10%; JP: 10%; CA: 10%; US: N/A (except for one sunscreen at 2%)

Ecamsule; INCI: Terephthalylidene Dicamphor Sulfonic Acid

EU: 10%; AU: 10%; JP: 10%; CA: 10%; US: N/A (except for one sunscreen at 2%)

Neo Heliopan AP (or Bidisulizole Disodium); INCI: Disodium Phenyl Dibenzimidazole Tetrasulfonate  EU: 10%; AU: 10%; JP: N/A; CA: N/A; US: N/A

Neo Heliopan AP (or Bidisulizole Disodium); INCI: Disodium Phenyl Dibenzimidazole Tetrasulfonate

EU: 10%; AU: 10%; JP: N/A; CA: N/A; US: N/A

Meridamate; INCI: Menthyl Anthranilate  EU: N/A; AU: 5%; JP: N/A; CA: 5%; US: 5%

Meridamate; INCI: Menthyl Anthranilate

EU: N/A; AU: 5%; JP: N/A; CA: 5%; US: 5%

All of them!

All of them!

Solid UVB & UVA II Filters

Uvinul T 150 (or Octyl Triazone); INCI: Ethylhexyl Triazone  EU: 5%; AU: 5%; JP: 5%; CA: N/A; US: N/A

Uvinul T 150 (or Octyl Triazone); INCI: Ethylhexyl Triazone

EU: 5%; AU: 5%; JP: 5%; CA: N/A; US: N/A

Iscotrizinol (or Uvasorb HEB); INCI: Diethylhexyl Butamido Triazone  EU: 10%; AU: N/A; JP: N/A (I think); CA: N/A; US:N/A

Iscotrizinol (or Uvasorb HEB); INCI: Diethylhexyl Butamido Triazone

EU: 10%; AU: N/A; JP: N/A (I think); CA: N/A; US:N/A

Enzacamene; INCI: 4-Methylbenzylidene Camphor  EU: 4%; AU: 4%; JP: N/A; CA: 4%; US: N/A

Enzacamene; INCI: 4-Methylbenzylidene Camphor

EU: 4%; AU: 4%; JP: N/A; CA: 4%; US: N/A

Ensulizole; INCI: Phenylbenzimidazole Sulfonic Acid  EU: 8%; AU: 4%; JP: 3%; CA: 4%; US: 4%

Ensulizole; INCI: Phenylbenzimidazole Sulfonic Acid

EU: 8%; AU: 4%; JP: 3%; CA: 4%; US: 4%

Titanium Dioxide  EU: 25%; AU: 25%; JP: No Limit; CA: 25%; US: 25%

Titanium Dioxide

EU: 25%; AU: 25%; JP: No Limit; CA: 25%; US: 25%

Oxybenzone; INCI: Benzophenone-3  EU: 6%; AU: 10%; JP: 5%; CA: 6%; US: 6%

Oxybenzone; INCI: Benzophenone-3

EU: 6%; AU: 10%; JP: 5%; CA: 6%; US: 6%

Sulisobenzone; INCI: Benzophenone-4  EU: 5%; AU: 10%; JP: 10%; CA: 10%; US: 10%

Sulisobenzone; INCI: Benzophenone-4

EU: 5%; AU: 10%; JP: 10%; CA: 10%; US: 10%

All of them!

All of them!

Liquid UVB & UVA II Filters

Padimate-O; INCI: 2-Ethylhexyl Dimethyl PABA  EU: 8%; AU: 8%; JP: 10%; CA: 8%; US: 8%

Padimate-O; INCI: 2-Ethylhexyl Dimethyl PABA

EU: 8%; AU: 8%; JP: 10%; CA: 8%; US: 8%

Amiloxate; INCI: Isoamyl p-Methoxycinnamate  EU: 10%; AU: 10%; JP: 10%; CA: N/A; US: N/A

Amiloxate; INCI: Isoamyl p-Methoxycinnamate

EU: 10%; AU: 10%; JP: 10%; CA: N/A; US: N/A

Octinoxate; INCI: Ethylhexyl Methoxycinnamate  EU: 10%; AU: 10%; JP: 20%; CA: 7.5% US: 7.5%

Octinoxate; INCI: Ethylhexyl Methoxycinnamate

EU: 10%; AU: 10%; JP: 20%; CA: 7.5% US: 7.5%

Octocrylene  EU: 10%; AU: 10%; JP: 10%; CA: 10% US: 10%

Octocrylene

EU: 10%; AU: 10%; JP: 10%; CA: 10% US: 10%

Octisalate (or Octyl Salicylate); INCI: Ethylhexyl Salicylate  EU: 5%; AU: 5%; JP: 10%; CA: 5%; US: 5%

Octisalate (or Octyl Salicylate); INCI: Ethylhexyl Salicylate

EU: 5%; AU: 5%; JP: 10%; CA: 5%; US: 5%

Polysilicone-15  EU: 10%; AU: 10%; JP: 10%; US: N/A

Polysilicone-15

EU: 10%; AU: 10%; JP: 10%; US: N/A

Homosalate (or Homomethyl Salicylate)  EU: 10%; AU: 15%; JP: 10%; CA: 15%; US: 15%

Homosalate (or Homomethyl Salicylate)

EU: 10%; AU: 15%; JP: 10%; CA: 15%; US: 15%

All of them!

All of them!

Please be adivsed I have left off several filters which I have literally never seen in sunscreen products. They include Dioxybenzone, Cinoxate, PABA, Trolamine Salicylate, several more. These don't really play a role in sun protecting products as sold to consumers.

Cited

Extinction Spectra from:

Osterwalder, U., & Herzog, B. (2009). Chemistry and Properties of Organic and Inorganic UV Filters. In Editor H. W. Lim & Z. D. Draelos (Eds.), Clinical Guide to Sunscreens and Photoprotection (pp. 33). New York, NY: Informa Healthcare USA, Inc

& BASF Care Creations

Sunscreen Regulations:

Austrailia | Canada | Europe | Japan & Japan (again) | United States
